Rear Panel
This appendix displays the rear panel of all switches covered by this guide.
Note: Depending on the components used to populate the chassis, the appearance of a specific switch could be different.
![](/assets/images/qsg/qsg-7800-series/Graphics/Rear%20Panel/DCS-7804%20Rear%20III.png)
1 | ESD attachment point | 3 | Fabric modules | 5 | Fabric module ejector lever |
2 | Chassis ground | 4 | Fabric module screw |
![](/assets/images/qsg/qsg-7800-series/Graphics/Rear%20Panel/DCS-7808%20Rear%20View.png)
1 | Fabric module screw | 3 | Chassis ground |
2 | Fabric module ejector lever | 4 | ESD attachment point |
![](/assets/images/qsg/qsg-7800-series/Graphics/Rear%20Panel/DCS-7812%20Rear%20View%20III.png)
1 | ESD attachment point | 4 | Fabric module ejector lever |
2 | Fabric module release button | 5 | Fabric module release button |
3 | Fabric module ejector lever |
![](/assets/images/qsg/qsg-7800-series/Graphics/Rear%20Panel/DCS-7816_Rear.png)
1 | Fabric module screw | 5 | ESD attachment point | 9 | Fabric module |
2 | Fabric module ejector lever | 6 | Fabric module screw | ||
3 | Fabric module screw | 7 | Fabric module ejector lever | ||
4 | Fabric module | 8 | Fabric module screw |
