Rear Panel
This appendix displays the rear panel of all appliances covered by this guide.
![](/assets/images/qsg/qsg-etm-q6e/Graphics/Rear%20Panel/Q6E_Rear_ports.png)
1 | LAN Gb Ethernet ports | 5 | Console port |
2 | SFP WAN ports | 6 | Power button |
3 | Ethernet WAN ports | 7 | Power supply port |
4 | 3.0 USB ports |
Note: The SFP WAN ports and Ethernet WAN ports are "combo ports". A choice must be made between SFP and Ethernet ports for the designated port number.
