Rear Panel

This appendix displays the rear panel of all switches covered by this guide.

Note: Depending on the components used to populate the chassis, the appearance of a specific switch could be different.



Figure 1. DCS-7804 Rear Panel (Fully Populated)
1 ESD attachment point 3 Fabric modules 5 Fabric module ejector lever
2 Chassis ground 4 Fabric module screw



Figure 2. DCS-7808 Rear Panel (Fully Populated)

1 Fabric module screw 3 Chassis ground
2 Fabric module ejector lever 4 ESD attachment point



Figure 3. DCS-7812 Rear Panel (Fully Populated)
1 ESD attachment point 4 Fabric module ejector lever
2 Fabric module release button 5 Fabric module release button
3 Fabric module ejector lever



Figure 4. DCS-7816 Rear Panel (Fully Populated)

1 Fabric module screw 5 ESD attachment point 9 Fabric module
2 Fabric module ejector lever 6 Fabric module screw
3 Fabric module screw 7 Fabric module ejector lever
4 Fabric module 8 Fabric module screw
