Front Panel



This section displays the front panel of all Awake Security appliances covered by this guide.



Note: All devices are designed to fit into a 19” rack. The appearance may be different than those shown based on PSU and fan modules used.





1 Unused port 2 Unused port 3 Control panel
4 Right rack ear brackets 5 Storage drives 6 Left rack ear brackets



Figure 1. DCA-NDR-A5, DCA-NDR-NB10, DCA-NDR-S5, DCA-NDR-S10
1 Storage drives 2 NVMe - A5 and NB10 only 3 Service/Asset tag
4 Control panel
