Front Panel

This appendix displays the front panel of all switches covered by this guide.

Figure 1. CCS-755 Front Panel (Fully Populated)

1 Grounding locations 3 Linecards
2 ESD attach point 4 Supervisor modules



Figure 2. CCS-758 Front Panel (Fully Populated)

1 Grounding locations 3 Linecards
2 ESD attach point 4 Supervisor modules
